ReFlex Series
PRN80190 Rev. 1.94 Aug.2023
Installation Guidelines
Ensure you consider and meet the installation guidelines below.
Ventilation Requirements
This cabinet must have the following ventilation clearances at all times:
*When installed for continuous duty in a climate class 7 environment (35°C ambient / 75% relative humidity), SKOPE recommends
providing 50 mm clearance around the sides and back of the cabinet.
Cleaning Before First Use
You must thoroughly clean and sanitise the cabinet interior, drawers and food contact surfaces such as the worktop before first
use. Ensure the cabinet is not plugged into the power supply before cleaning, and use only standard stainless steel cleaners
suitable for food preparation areas. If required, clean the outside of the cabinet as instructed on the back page of this user guide.
Ventilation
Ensure all ventilation
requirements below
are met.
Door/Drawer Opening
Allow adequate space
for the door/s to open
and close properly.
Sunlight
Do not install the cabinet in
direct sunlight.
Uneven Surface
Do not install the
cabinet on an uneven
surface.
Surface
The installation
surface must be
capable of supporting
the loaded cabinet.
Power Supply
Do not overload the
power supply.
Blocking Ventilation
Do not store boxes or
items in front or on
top of the cabinet.
Climate Class
The cabinet must be
installed in an environment
within its climate class.
The climate class is stated
on the cabinet rating label,
and explained on the front
page of this user guide.
The rating label is located inside
the cabinet at the top front of the
left or right side wall.
If the cabinet has drawers it may
be necessary to remove the top
drawer to view the label.
No below clearance required
Min. 300 mm above
No side
clearance
required
No behind
clearance
required
No side
clearance
required
No behind
clearance
required
No below clearance required
No above clearance required
Upright Cabinets Underbench Cabinets
Keep area in front of grille
and doors/drawers clear
Keep area in front
of doors clear
*
*
*
*
No below clearance required
Min. 100 mm
left side
Keep area in front of
grille and drawers clear
ChefBase Cabinets
No behind
clearance
required
*
No above clearance required
