F-600 Gate Opener FA30 Ph otocell
WARNGING: Make sure the cables you used meet with the above installation
types and the wiring system is in a safety ground surrounding.
WARNING: Important safety instructions. Follow all instructions
since incorrect installation can lead to severe injury.
- Before installing the drive ,check whether t he d riven p art is in good mechanical condition,
correctly balanced and open or close properly.
- The drive cannot be used with a driven part incorporating a wicket door.
- Whether the actuating member of a biased-off switch is to be located within direct sight of
the driven part but away from moving parts. Unless it is key operated, it is to be installed
at a minimum height of 1.5 m and not accessible to the public.
Measurement
gearmo tor
rear brackets
Please refer to Table 1 on page 7, Value B will depend on Value A and the
Maximum Opening Angle of the gate leaf
.
