SECTION 6, Page 23SJIII Series - The Conventionals 129919
A (Ref.) - ASSEMBLY, Hydraulic Hose Connection - Model 3220/4620
B (Ref.) - ASSEMBLY, Hydraulic Hose Connection - Model 4626
1 (Ref.) - ASSEMBLY, Power deck cylinder
(For components, refer to Figure 6.1-11)
2 125883 AR FITTING, Elbow 90° Connector
3 132463 1 FITTING, Tee Connector, B
4 108507 AR PLUG, Hydraulic
5 126366 1 FITTING, Elbow 90° Connector
6 127995 1 HOSE ASSEMBLY, 1/4” dia. x 300” - Return line, A
132459 1 HYDRAULIC HOSE, 1/4” dia. x 380” - Return line, B
7 127994 1 HOSE ASSEMBLY, 1/4” dia. x 312” - Supply line, A
132460 1 HYDRAULIC HOSE, 1/4” dia. x 392” - Supply line, B
8 (Ref.) 1 FITTINGS, Main Manifold
(For components, refer to Figure 6.4-5)
9 132462 1 HYDRAULIC HOSE, 1/4” dia. x 103”, B
10 125828 1 HYDRAULIC HOSE, 3/16” dia. x 72.75”
11 132461 1 HYDRAULIC HOSE, 1/4” dia. x 31”, B
12 115320 1 PLUG, Hydraulic, B
13 103605 2 SOLENOID, 24V Valve
14 113953 1 VALVE, Four Way Spool
Index
No.
Skyjack
Part No.
DescriptionQty.
Figure 6.1-12. Powered Extension Hydraulic Hose and Fittings Assembly
