SECTION 6, Page 29SJIII Series - The Conventionals 129919
Figure 6.1-17. Operator’s Control Box Assembly (ANSI/CSA)
Index
No.
Skyjack
Part No.
DescriptionQty.
A 116063 - CONTROL BOX ASS’Y, (ANSI & CSA No Option)
B 126205 - CONTROL BOX ASS’Y, (ANSI & CSA) (Equipped with Powered Extension Deck)
C 117228 - CONTROL BOX ASS’Y, (ANSI & CSA) (EE Rated Option)
1 102956 1 PLUG, Plastc 1/2”, B, C
2 103036 2 CONNECTOR, Cable Strain Relief 1/2”, B
3 132098 1 COVER, Bottom with horn cutout, A
310625 1 COVER, Bottom with horn cutout, B, C
112327 9 • SCREW, Hex hd self-tapping #8-18 x 1/2
4 300788 1 CONNECTOR, Cable Strain Relief
5 (Ref.) 1 SWITCH ASSEMBLY, Horn push-button
102851 1 • HEAD, Push-button switch
103100 1 • BASE, Contact
103141 1 • SWITCH, N.O. Single Pole Contact
6 124153 1 GUARD, Control Box
103962 6 • BOLT, Machine #10 - 32 x 1/2”
104185 6 • WASHER, Lock #10 NOM
104694 2 • WASHER, Flat #10 S.A.E.
104003 2 • NUT, Machine #10 - 32 Gr. B
7 113451 1 MOUNT, Terminal strip
8 103012 AR BLOCK, Terminal
9 112327 2 • SCREW, Round Hd Machine #8 - 18 x 1/2”
10 103985 AR • NUT, Hex head #6 - 32
11 111181 2 GUARD, Toggle switch
12 115574 1 SWITCH, Torque toggle
13 116382 1 SWITCH, Lift/off/drive toggle
14 122093 1 INDICATOR, Battery charge
15 132096 1 CASING, Control Box, A
128871 1 CASING, Control Box, B, C
Parts list continued on the following page.
