SECTION 6, Page 31SJIII Series - The Conventionals 129919
Figure 6.1-17. Operator’s Control Box Assembly (ANSI/CSA) (Continued)
Index
No.
Skyjack
Part No.
DescriptionQty.
Parts list continued from the previous page.
16 (Ref.) 1 CONTROLLER ASSEMBLY, Proportional
- (For components, refer to Figure 6.1-19)
17 (Ref.) 1 SWITCH ASSEMBLY, Key off/on, A, B, C
102754 1 • HEAD, 2-Position key switch
104466 AR • KEY, #455
103100 1 • BASE, Contact
103141 1 • SWITCH, N.O. Single Pole Contact
100149 1 • WASHER, Switch
18 (Ref.) 1 SWITCH ASSEMBLY, Emergency stop
102769 1 • HEAD, Stop switch
103100 1 • BASE, Contact
103225 1 • SWITCH, N.C. Single Pole Contact
100149 1 • WASHER, Switch
19 121058 1 HORN, 24 Volt operator
116220 2 • SCREW, Machine M4 x 0.7 x 16 mm
121484 4 • NUT, Hex Nylon M4 x 0.70
20 (Ref.) 1 CABLE ASSEMBLY, 10 Pin Electrical Panel Control
- (For components, refer to Figure 6.6-2)
21 (Ref.) 1 CABLE ASSEMBLY, Scissor Arm
(For components, refer to Figure 6.1-20)
22 119731 1 CABLE ASSEMBLY, Control box, B
107820 1 • CONNECTOR ASSEMBLY, 16 Pole male
102887 37" • CABLE, 16/15
118711 2 • LABEL, Hydraulic proportional
119727 2 • CODE PIN
23 119642 1 CABLE ASSEMBLY, Control box, A
102888 37" • CABLE, 16/10
102766 1 • PLUG, 10 Pole male
119456 2 • COVER, CONNECTOR
118711 2 • LABEL, Hydraulic proportional
24 103257 AR CORD, Cabtire 18/3 (Power Deck Control Box)
25 103257 27” CORD, Cabtire 18/3 (Power Deck Solenoid)
26 107711 3 CONNECTOR ASSEMBLY, 5 Pole female
103568 1 • HOUSING, Female with Strain relief connector
132789 1 • • HOUSING
132110 1 • • CONNECTOR, Strain relief
103570 1 • INSERT, Female
27 (Ref.) 1 CABLE ASSEMBLIES (Powered extension option)
(For components, refer to Figure 6.1-13, & 6.1-14)
L (Ref.) 1 LABEL, Control Box
- (Refer to Figure 6.8-2)
