SECTION 6, Page 33SJIII Series - The Conventionals 129919
A 130593 - CONTROL BOX, Assembly (Equipped with Manual Extension Deck)
B 130595 - CONTROL BOX, Assembly (Model 3220/46XX Equipped with Powered Ext.)
C 130594 - CONTROL BOX, Assembly (Model 46XX with Powered Extension)
1 130564 1 WELDMENT, Control Box
2 (Ref.) - JOYSTICK, Controller Proportional.
(For components, refer to Figure 6.1-19)
300831 2 SCREW, Machine Flat Head #10 - 32 x 5/8
3 122093 1 INDICATOR, Battery Charger
4 103962 4 SCREW, Round Hd Machine #10 - 32 x 1/2”
5 111181 AR GUARD, Toggle Switch
6 115574 1 SWITCH, Torque Toggle
7 124153 1 GUARD, Joystick
104694 2 • WASHER, Flat #10
104185 4 • WASHER, Lock #10
104003 4 • NUT, Machine #10 - 32
8 103012 1 BLOCK, Terminal 12 Position Small
103955 2 • SCREW, PPHMS #6 - 32 x 3/4
103985 2 • NUT, Hex Head #6 - 32
106099 2 • WASHER, Lock #6
9 (Ref) 1 ASSEMBLY, Horn Switch
102851 1 • HEAD, Push Button Switch
103100 1 • BASE, Block Contact
103141 1 • SWITCH, N.O. Contact
10 (Ref.) 1 ASSEMBLY. Key Switch
103082 1 • HEAD, Key Switch 3 Position
103100 1 • BASE, Block Contact
103141 AR • SWITCH, N.O. Contact
100149 1 • WASHER, Switch Mount
11 (Ref.) 1 ASSEMBLY, Emergency Stop Switch
102769 1 • HEAD, Emergency Stop Switch
103100 1 • BASE, Block Contact
103225 1 • SWITCH, N.C. Contact
100149 1 • WASHER, Switch Mount
Part list continued on the following page.
Index
No.
Skyjack
Part No.
DescriptionQty.
Figure 6.1-18. Operator’s Control Box Assembly (CE)
