Part list continued from the previous page.
12 114710 1 RING, Key Skyjack Logo
13 310625 1 WELDMENT, Control Box Bottom Cover
112327 9 • SCREW, Hex Hd Self-tapping #8-18 x 1/2”
14 300788 1 CONNECTOR, Strain Relief
15 121058 1 HORN, 24 Volt
116220 2 • SCREW, Machine M4 x 0.7 x 16mm
121484 4 • NUT, Hex Nylon Lock M4 x 0.70
16 119731 1 CABLE ASSEMBLY, Control box
107820 1 • CONNECTOR ASSEMBLY, 16 Pole male
102887 27” • CABLE, 16/15
118711 2 • LABEL, Hydraulic proportional
119727 2 • CODE, Pin
17 116382 1 SWITCH, Lift/Off/Drive Toggle
18 (Ref.) 1 ASSEMBLY, On/Overload Light
103202 1 • CAP, Top Light Cover
102771 1 • BULB, 24 Volt
102671 1 • MOUNT, Base Light
19 300460 AR PLUG, Snap In 7/8” Hole, A, B
20 (Ref) - ASSEMBLY, Scissor Arm Control Cable
21 103257 AR CORD, Cabtire 18/3 (Power Deck Control Box), B, C
22 103256 AR CORD, Cabtire 18/2 (Power Deck Limit Switch), C
23 103255 27” CORD, Cabtire 18/4 (Power Deck Solenoid), B, C
24 107711 3 CONNECTOR ASSEMBLY, 5 Pole female
103568 1 • HOUSING, Female with Strain relief connector
132789 1 • • HOUSING
132110 1 • • CONNECTOR, Strain relief
103570 1 • INSERT, Female
L (Ref.) 1 LABEL, Control Box
- (Refer to Figure 6.8-2)
Index
No.
Skyjack
Part No.
DescriptionQty.
Figure 6.1-18. Operator’s Control Box Assembly (CE) (Continued)
