SECTION 6, Page 49SJIII Series - The Conventionals 129919
1 121674 1 PIN, Outside Scissor
2 123430 2 BUSHING, Fiberglide 3/4”I.D. x 1-1/2”
3 121874 1 COTTER PIN, 1/4” x 1.5”
4 121605 1 TUBE, Outside scissor arms Cross Member (Model 32XX)
121672 1 TUBE, Outside scissor arms Cross Member, (Model 46XX)
5 120958 1 PIN, Inside Scissor
6 121677 1 PIN, Limit Switch
7 (Ref.) - ASSEMBLY, Limit Switch
(For Components, Refer to Figure 6.2-7)
8 128256 AR ASSEMBLY, Center Pin (Scissor level without Cable Carrier Weldment)
130385 AR ASSEMBLY, Center Pin (Scissor level with Cable Carrier Weldment)
9 120673 1 • PIN, Center
10 101520 1 • WASHER, Nylon 2”O.D. x 1.28” I.D. x 0.12” thk
11 123431 4 • BUSHING, Fiberglide 1-1/4” x 1-13/16”
12 121703 1 • SPACER, Bearing Thrust Fiberglide 1-1/4” I.D.
*13 122502 1 • WASHER, Flat 1-1/4”I.D. x 2-1/4” O.D.
14 121875 1 • COTTER PIN, 5/16” dia. x 2.0”
* Note: Not required if equipped with Cable Carrier Weldment
Index
No.
Skyjack
Part No.
DescriptionQty.
Figure 6.2-5. Scissor Arm Assembly Connecting Hardware
