SECTION 6, Page 51SJIII Series - The Conventionals 129919
Figure 6.2-6. Flashing Amber Light Option
Index
No.
Skyjack
Part No.
DescriptionQty.
10113AA
1 121838 1 LIGHT ASSEMBLY, Flashing amber (without Terminals)
126111 1 LIGHT ASSEMBLY, Flashing Amber (with Terminals included as shown)
121477 1 • LIGHT, Beacon
121533 1 • • LENS, Amber
103111 1 • • BULB, 24 Volt (if equipped with single contact bulb)
146153 1 • • BULB, 24 Volt (if equipped with dual contact bulb)
2 103743 1 FLASHER, 12-24 Volt
3 123180 1 COVER ASSEMBLY (Optional For EE Rated Machines)
123177 1 • COVER, Flashing Light
4 123178 1 • BRACKET, Flashing Light Cover
120094 4 • BOLT, #10-32 x 5/8”
104003 4 • NUT, #10-32
104694 4 • WASHER, #10 Flat
104185 4 • WASHER, #10 Lock
5 141566 1 HARNESS, Flashing light (Machines with S/N 60000967 & Above)
103256 100” • CABTIRE, 18/2
126104 1 HARNESS, Flashing light (Model 3220)
(For Machines with S/N 60000966 & Below)
103256 48” • CABTIRE, 18/2
126100 1 HARNESS, Flashing light (Model 3226)
(For Machines with S/N 27002839 & Below)
103256 228” • CABTIRE, 18/2
132283 1 HARNESS, Flashing Light Option (Model 46XX)
(For Machines with S/N 70003077 & Below)
103256 60” • CABTIRE, 18/2
6 (Ref.) - HARNESS, Rear Manifold
(For components, refer to Figure 6.6-1)
5
2
1
4
3
6
AI
