Skyjack 4632 - Page 145

SECTION 6, Page 59
SJIII Series - The Conventionals 129919
Figure 6.3-1. Base, Axle & Wheels
Index
No.
Skyjack
Part No.
DescriptionQty.
1 132769 1 BAR ASSEMBLY, Emergency lowering
132477 1 • BAR, Emergency lowering access
119920 2 • CLIP, Spring coated
103991 2 • WASHER, Flat #8
132768 2 • RIVET, Pop 5/32” dia. x 0.435”
124160 2 • PIN, Locking
2 103199 20 BOLT, Wheel
3 (Ref.) 1 ROD ASSEMBLY, Tie
- (For components, refer to Figure 6.3-5)
4 (Ref.) 1 CYLINDER ASSEMBLY, Steer
- (For components, refer to Figure 6.3-6)
5 125730 2 PIN ASSEMBLY, King
100120 1 • PIN, Axle king
100825 1 • PIN, 1/4" x 1-3/16" lg.
103478 1 • PIN, Cotter 1/4" x 1-1/4" lg.
104129 1 • WASHER, Bronze
6 (Ref.) 1 HUB & SPINDLE ASSEMBLY, Front Axle
- (For components, refer to Figure 6.3-4)
7 125785 2 WHEEL ASSEMBLY, Front (ITL)
132285 2 WHEEL ASSEMBLY, Front (Carlisle)
8 132473 1 WELDMENT, Base (Model 3220 without Powered Extension)
132471 1 WELDMENT, Base (Model 3226 & Model 3220 with Powered Extension)
130179 1 WELDMENT, Base (Model 46XX with serial numbers 713314 and below)
136494 1 WELDMENT, Base (Model 46XX with serial numbers 713315 and above)
9 (Ref.) TILT SWITCH
- (For components, refer to Figure 6.3-12)
103855 2 • BOLT, Hex Hd 1/4”-20 x 1/2” Gr. 5
103980 2 • NUT, Hex Hd 1/4”-20 Gr. B
104000 2 • WASHER, Lock 1/4”
10 130192 1 LADDER, Step (Model 3220/4620)
122307 1 LADDER, Step (Model 3226/4626/4632)
103999 4 • WASHER, 3/8” Lock
125959 4 • WASHER, 3/8” Flat
103473 4 • BOLT, Hex-hd 3/8-16 x 1” lg.
11 119725 1 SWITCH, Battery
108714 1 • KIT, Battery switch lockout
(Ref.) 1 • LABEL, Power on/off
- (Refer to Figure 6.8-3)
12 115005 1 ASSEMBLY, Static Strap
115420 1 • STRAP, Ground
101632 1 • BOLT, Hex head 3/8” - 16 x 3/4”
103999 1 • WASHER, Lock 3/8” NOM
103978 1 • NUT, Hex head 3/8” - 16
Part list continued on the following page.
