SECTION 6, Page 61
SJIII Series - The Conventionals 129919
Figure 6.3-1. Base, Axle & Wheels
Index
No.
Skyjack
Part No.
DescriptionQty.
Part list continued on the previous page.
13 (Ref.) 1 BOX ASSEMBLY, Base control (CE)
- (For components, refer to Figure 6.3-11)
14 102027 2 FITTING, Grease
15 (Ref.) 2 HUB ASSEMBLY, Rear axle
- (For components, refer to Figure 6.3-3)
16 (Ref.) 2 MOTOR, Wheel drive (Equipped with Pin Brake)
(For components, refer to Figure 6.3-3)
(Ref.) 2 MOTOR, Wheel drive (Equipped with Motor Brake)
(For components, refer to Figure 6.3-3)
17 141751 4 SET SCREW, Square head, cup point (3/8-16 x 3/4, Grade 5)
18 124228 1 WELDMENT, Brake pin LH
103940 1 • BOLT, Soc-hd 1/4-20 x 1-1/4" lg.
104000 1 • WASHER, Lock 1/4"
103983 1 • NUT, Jam 1/4-20
19 (Ref.) 2 CYLINDER ASSEMBLY, Brake
- (For components, refer to Figure 6.3-7)
20 124229 1 WELDMENT, Brake pin RH
103940 1 • BOLT, Soc-hd 1/4-20 x 1-1/4" lg.
104000 1 • WASHER, Lock 1/4"
103983 1 • NUT, Jam 1/4-20
21 (Ref.) 1 POTHOLE PROTECTION DEVICE ASSEMBLY
- (For components, refer to Figure 6.3-2)
22 (Ref.) 1 BATTERY TRAY ASSEMBLY
- (For components, refer to Figure 6.5-1)
(Ref.) 1 HYDRAULIC/ELECTRIC TRAY ASSEMBLY
- (For components, refer to Figure 6.4-1)
DO NOT
Intermix tires of different types
on one machine. Use only tires
of type originally supplied.
