Skyjack 4632 - Page 148

SECTION 6, Page 63
SJIII Series - The Conventionals 129919
Figure 6.3-2. Pothole Protection Device
Index
No.
Skyjack
Part No.
DescriptionQty.
1 136417 AR COMPRESSION ROD, Assembly
2 125776 2 CAM, Lock Assembly
3 119314 2 • SPRING, Cam Lock
4 119728 4 • WASHER, Driver
5 119499 2 • LOCK, Cam
6 118778 2 • BUSHING, Cam Lock
7 118730 2 • PIN, Lever Bar Guide
8 118718 2 • DRIVER, Lock
119843 2 • PIN, Spring 3/32 x 1-3/8
9 118729 2 • PIN, Locator
10 139698 1 • WASHER, 3/4” Flat
11 119313 8 WASHER, Flat 7/16
12 119325 8 PIN, Clotter Clip
13 100446 2 PIN, Eccentric
14 119312 6 BUSHING, 7/16 x 1/2
15 118724 2 BAR, Lever
16 118983 2 PIN, Lower Tray
17 119321 2 SPRING, Kicker
18 126709 1 WELDMENT, Hydraulic Tray Angle
19 126710 1 WELDMENT, Battery Tray Angle
20 119339 4 PIN, Angle
21 119316 16 BUSHING, 3/8 x 5/8
22 119029 2 LOCK, Tray Cam
23 119319 8 PIN, Spring 3/32 x 5/8
24 119322 2 PLATE, Kicker
25 118689 2 PIN, Kicker Clevis
26 119318 4 BUSHING, 7/16 x 3/8
27 118690 2 PIN, Lock
28 119315 2 PIN, Spring 3/32 x 7/8
Parts list continued on the following page.
