Figure 6.3-2. Pothole Protection Device (Continued)
Index
No.
Skyjack
Part No.
DescriptionQty.
Parts list continued from the previous page.
29 129430 2 MOUNT, Limit Switch
103983 4 • NUT, Hex Jam 1/4”
103995 4 • WASHER, Flat 1/4”
30 (Ref.) 1 SWITCH ASSEMBLY, Pothole device limit - Model 32xx (ANSI/CSA & CE) &
Model 46xx (ANSI/CSA)
125887 1 • SWITCH, Limit pothole battery tray
125885 1 • SWITCH, Limit pothole hydraulic tray
(Ref.) 1 SWITCH ASSEMBLY, Pothole device limit - Model 46xx (CE)
133600 1 • SWITCH, Limit pothole hydraulic tray
133601 1 • SWITCH, Limit pothole battery tray
(Ref.) 1 SWITCH ASSEMBLY, Pothole device limit - All EE Rated Models
126051 1 • SWITCH, Limit pothole battery tray
126060 1 • SWITCH, Limit pothole hydraulic tray
31 104185 4 WASHER, Lock #10
32 112248 4 BOLT, Machine #8-32 x 1” lg.
33 103550 6 PLUG, Slider
34 130049 1 FLAP WELDMENT, Hydraulic Tray
35 130047 1 FLAP WELDMENT, Battery Tray
36 (Ref.) - HARDWARE, Flap weldment retaining
104000 4 • WASHER, 1/4” Lock
103995 4 • WASHER, 1/4” Flat
103855 4 • BOLT, Hex-hd 1/4”-20 x 1/2” lg.
37 130209 4 PIN, Lever
38 132530 2 PIN, Tray spring guide
39 118992 2 MOUNT, Limit switch
112248 4 BOLT, Machine #8 - 32 x 1” lg.
104185 4 WASHER, Lock #10 NOM
