Skyjack 4632 - Page 151

SECTION 6, Page 67
SJIII Series - The Conventionals 129919
Figure 6.3-3. Brake Reference
Index
No.
Skyjack
Part No.
DescriptionQty.
- - - • Base, Axles, and Wheels
(For components, refer to Figure 6.3-1)
1 125795 1 REAR HUB ASSEMBLY
107912 1 • HUB, Rear 1-1/4” Shaft
2 103789 1 WASHER, Lock toothed 1”
3 103129 1 MOTOR, Hydraulic Wheel Drive
104212 1 • KIT, Seal
4 (Ref.) - FITTINGS, Hydraulic (Pin Brake)
(For components, refer to Figure 6.3-9)
5 106451 1 NUT, Hex jam 1” - 20
6 108818 4 BOLT, Hex head 1/2” - 13 x 2-3/4”
7 103471 4 NUT, Hex head 1/2” - 13
8 103470 4 WASHER, Lock 1/2”
9 125786 2 WHEEL ASSEMBLY, Rear (ITL)
132284 2 WHEEL ASSEMBLY, Rear (Carlisle)
10 (Ref.) - • BRAKE CYLINDER ASSEMBLY
(For components, refer to Figure 6.3-7)
11 134573 1 MOTOR, Wheel (with internal Disc Brake)
139735 1 • KIT, Seal
12 137462 1 KEY
13 (Ref.) - FITTINGS, Hydraulic (Disc Brake)
(For components, refer to Figure 6.3-10)
14 125525 4 BOLT, Hex head 1/2” - 13 x 3-1/2”
15 125785 2 WHEEL ASSEMBLY, Rear (ITL)
132285 2 WHEEL ASSEMBLY, Rear (Carlisle)
