Skyjack 4632 - Page 160

SECTION 6, Page 77
SJIII Series - The Conventionals 129919
Figure 6.3-10. Hydraulic Hose Connections (Disc Brake)
46XX Machines (For Serial No. Breakdown Refer to Figure 6.3-3)
Index
No.
Skyjack
Part No.
DescriptionQty.
Machines Equipped with Disc Brake
(Refer to Figure 6.3-3)
1 (Ref.) - CYLINDER ASSEMBLY, Steer
- (For components, refer to Figure 6.3-6)
2 105811 1 ORIFICE, .040 Diameter
3 103069 2 FITTING, Connector #6 orb - #6
4 119833 2 HOSE ASSEMBLY, Steer
5 104656 2 HOSE ASSEMBLY, Drive
6 137175 1 HOSE ASSEMBLY, Brake supply
7 (Ref.) 1 MANIFOLD ASSEMBLY, Main
- (For components, refer to Figure 6.4-4)
8 136569 2 HOSE ASSEMBLY, Wheel Motor
9 103071 4 FITTING, Adapter #10 orb - #8
10 (Ref.) 2 MOTOR, Wheel, With Disc Brake
(For components, refer to Figure 6.3-3)
11 125883 1 FITTING, 90° Elbow 04MJ04MB
12 113348 1 FITTING, 90° Elbow #515-6-4
13 136573 1 HOSE ASSEMBLY, Right Brake
14 136568 2 HOSE ASSEMBLY, Wheel Motor
15 136576 1 HOSE ASSEMBLY, Right Motor Drain
16 (Ref.) 1 MANIFOLD ASSEMBLY, Rear drive
- (For components, refer to Figure 6.3-8)
17 136540 1 MANIFOLD, Brake Release
125741 2 • BOLT, Hex Head 3/8”-16 x 7/8” gr8
101632 2 • BOLT, Hex Head 3/8”-18 x 3/4” gr5
103472 2 • WASHER, Flat 3/8”
103999 2 • WASHER, Lock 3/8”
18 126128 3 FITTING, Hydraulic
19 136572 1 HOSE ASSEMBLY, Brake Release Manifold
20 136574 1 HOSE ASSEMBLY, Left Brake
21 121602 1 FITTING, Tee #6804 -06-04-06
22 138133 1 HOSE ASSEMBLY, Main Case Drain
AH
