Skyjack 4632 - Page 159

SECTION 6, Page 76
SJIII Series - The Conventionals 129919
Left
Wheel
Motor
Right
Wheel
Motor
Rear
Drive
Mani-
fold
Main
Manifold
Steer
Cylinder
11544AA
Brake Release
Manifold
Figure 6.3-10. Hydraulic Hose Connections (Disc Brake)
46XX Machines (For Serial No. Breakdown Refer to Figure 6.3-3)
3
10
9
9
8
19
20
9
22
14
18
16
15
17
14
13
9
8
5
6
2
3
4
1
4
7
5
10
21
Drain To
Hydraulic
Tank
12
11
11
AH
NOTE: DISC BRAKE use on
46XX Machines (Refer to Serial
Number Breakdown Reference
Charts - Figure 6.3-3)
