SECTION 6, Page 75
SJIII Series - The Conventionals 129919
Figure 6.3-9. Hydraulic Hose Connections (Pin Brake)
32XX and 46XX Machines (For Serial No. Breakdown Refer to Figure 6.3-3)
Index
No.
Skyjack
Part No.
DescriptionQty.
Machines Equipped with Pin Brake
(Refer to Figure 6.3-3)
1 (Ref.) - CYLINDER ASSEMBLY, Steer
- (For components, refer to Figure 6.3-6)
2 105811 3 ORIFICE, .040 Diameter
3 103069 2 FITTING, Connector #6 orb - #6
4 119833 2 HOSE ASSEMBLY, Steer
5 102611 2 HOSE ASSEMBLY, Drive (Model 32XX)
104656 2 HOSE ASSEMBLY, Drive (Model 46XX)
6 104487 1 HOSE ASSEMBLY, Brake supply (Model 32XX)
104659 1 HOSE ASSEMBLY, Brake supply (Model 46XX)
7 (Ref.) 1 MANIFOLD ASSEMBLY, Main
- (For components, refer to Figure 6.4-4)
8 125497 4 TUBE ASSEMBLY, Drive motor (Model 32XX)
130248 4 TUBE ASSEMBLY, Drive motor (Model 46XX)
9 103071 4 FITTING, Adapter #10 orb - #8
10 (Ref.) 2 MOTOR, Hydraulic drive
(For components, refer to Figure 6.3-3)
11 114578 2 FITTING, Elbow 90° #6 orb - #6
12 (Ref.) 1 CYLINDER ASSEMBLY, Brake
- (For components, refer to Figure 6.3-7)
13 102540 1 HOSE ASSEMBLY, Brake RH
119451 1 HOSE ASSEMBLY, Brake RH (Model 46XX)
14 126015 1 HOSE ASSEMBLY, Brake LH
15 (Ref.) 1 MANIFOLD ASSEMBLY, Rear drive
- (For components, refer to Figure 6.3-8)
AH
