SECTION 6, Page 79
SJIII Series - The Conventionals 129919
Figure 6.3-11. Base Control Box Option
Index
No.
Skyjack
Part No.
DescriptionQty.
A 131956 - BOX ASS’Y, Base control (ANSI/CSA)
B 130863 - BOX ASS’Y, Base control (CE)
C 136535 - BOX ASS’Y, Base control (46XX with serial numbers 713315 and above)
1 132174 1 • HARNESS, Switches to Electrical Panel, A
2 132207 1 • HARNESS, Switches to Electrical Panel, B
3 103257 12” • • CORD, 18/3, A
4 119131 1 • • KIT-4 POLE, Deutsch plug, A
5 103255 20.3” • • CORD, Cabtire 18/4, A
103260 20.3” • • CORD, Cabtire 18/5, B
6 119132 1 • • KIT-8 POLE, Deutsch plug
7 (Ref) - • • ASSEMBLY, Enable Switch
108854 1 • • • HEAD, Push Button Switch
103100 1 • • • BASE, Contact
103141 1 • • • SWITCH, Single Normally Open
103225 1 • • • SWITCH, Single Normally Closed, A
8 (Ref) - • • ASSEMBLY, Up/Down Switch
102837 1 • • • HEAD, Selector Switch
103100 1 • • • BASE, Contact
103141 2 • • • SWITCH, Single Normally Open
9 (Ref.) - • ASSEMBLY, Emergency Switch, B
102769 1 • • HEAD, Emergency Stop Switch
103281 1 • • CONTACT, Single Normally Close
103100 1 • • BASE, Contact Block
103225 1 • • 1-CONTACT BLOCK, N.C.
102956 1 • PLUG, Snap in 7/8”, A
10 127284 2 • BOLT, Hex Hd 1/4-20 x 2.5” Gr. 5
11 104000 2 • WASHER, Lock 1/4”
12 131954 2 • INSERT, Threaded 1/4”-20
13 130862 1 • PLATE, Front Base Control Mount
14 132701 1 • PLATE, Rear Cover A, B
15 134766 1 • PLATE, Rear Cover C
L (Ref.) 1 • LABELS
- (Refer to Figure 6.8-3)
AF
