Skyjack 4632 - Page 163

SECTION 6, Page 80
SJIII Series - The Conventionals 129919
Figure 6.3-12. Brake Release Manifold Assembly
Index
No.
Skyjack
Part No.
DescriptionQty.
M136504AC
- 136540 - BRAKE RELEASE MANIFOLD ASSEMBLY
1 146559 1 • PUMP ASSEMBLY
2 146560 1 • • HANDLE, Pump
3 146561 1 • VALVE ASSEMBLY
4 146562 1 • • HANDLE, Valve
5 146563 1 • BLOCK, Brake manifold
6 701954 3 • FITTING, Straight (4 JIC)
- 146564 1 KIT, Seal
AI
1
2
6
435
