SECTION 6, Page 111
SJIII Series - The Conventionals 129919
Figure 6.6-4. Electrical Panel - Harness (CE)
1 130562 1 HARNESS, Rear Manifold/Limit Switch (Model 3220/3226/46XX/4832)
102887 76” • CABTIRE, Cable 16/15
117583 2 • PLUG, Connector 8-Pin
117585 2 • WEDGE, Connector Plug 8-Pin
117593 11 • SOCKET, Connector Contact
117594 5 • PLUG, Connector Sealing
2 130671 1 HARNESS, Relays to Control Module
103257 108” • CABTIRE, Cable 18/3
116990 3 • PIN, Female Wire
3 130598 1 HARNESS, Panel Load Sensor to Control Module
102888 98” • CABTIRE, Cable 16/10
116990 8 • PIN, Female Wire
130449 1 • HOUSING, Male 12-Pole Plug
4 130559 1 HARNESS, High Speed/Override Limit Switch (Model 3220/3226/4832)
133662 1 HARNESS, High Speed/Override Limit Switch (Model 46XX)
(Order P/N 130559 for machines with Serial No. 66889 (4620),
709570 (4626), & below)
133599 AR • SWITCH ASSEMBLY, Modified Drilled Sealed (Model 46XX)
(Order P/N 121975 for machines with Serial No. 66889 (4620),
709570 (4626), & below)
121975 AR • SWITCH ASSEMBLY, Modified Drilled Sealed (Model 3220/3226/4832)
119132 1 • KIT, 8-Pole Connector
4a 113018 1 • MARKER, Brady wire #18
4b 113021 1 • MARKER, Brady wire #21
4c 113071 1 • MARKER, Brady wire #71
4d 145963 1 • LABEL, LS1A
4e 145964 1 • LABEL, LS1B
4f 145965 1 • LABEL, LS6
5 130649 1 HARNESS, Base Control with Charger Cut-Out Assembly (Model 3215/3219)
103278 1 • 2-N.O. CONTACT, Switch (Up/Down)
103100 1 • • BASE, Contact Block
103141 2 • • BLOCK, Switch N.O.
103280 1 • 1-N.O. CONTACT, Switch (Enable)
103100 1 • • BASE, Contact Block
103141 1 • • BLOCK, Switch N.O.
103281 1 • 1-SINGLE CONTACT, Switch (Emergency Stop)
103100 1 • • BASE, Contact Block
103225 1 • • 1-CONTACT BLOCK, N.C.
119132 1 • KIT, 8-Pole Connector
6 129171 1 HARNESS, Holding Valve (Model 3220/4620)
119825 1 • CONNECTOR, Solenoid with Diode
103256 69” • CABLE, Cabtire 18/2
129170 1 HARNESS, Holding Valve (Model 3226/4626/4832)
119825 2 • CONNECTOR, Solenoid with Diode
103256 278” • CABLE, Cabtire 18/2
Parts list continued on the following page.
Index
No.
Skyjack
Part No.
DescriptionQty.
