SECTION 6, Page 113
SJIII Series - The Conventionals 129919
Figure 6.6-4. Electrical Panel - Harness (CE) (Continued)
Parts list continued from the previous page.
7 (Ref.) 1 ASSEMBLY, Base Control Box (Model 3220/3226/46XX/4832)
(For Components, Refer to Figure 6.3-11)
8 130886 1 HARNESS, Charger Cut-Out
105269 175” • CABTIRE, 14/3
116992 1 • CONNECTOR, 2-Pole Plug Male
116990 2 • PIN. Female Wire
9 132838 1 HARNESS, Main Manifold
119825 4 • CONNECTOR, Solenoid with diode
102921 3 • DIODE
10 125887 1 HARNESS, Pothole Battery Tray Limit Switch (Model 3220/3226/4832)
133601 1 HARNESS, Pothole Battery Tray Limit Switch (Model 46XX)
(Order P/N 125885 for machines with Serial No. 66889 (4620),
709570 (4626), & below)
11 125885 1 HARNESS, Pothole Hydraulic Tray Limit Switch (Model 32XX/4832)
133600 1 HARNESS, Pothole Hydraulic Tray Limit Switch (Model 46xx)
(Order P/N 125887 for machines with Serial No. 66889 (4620),
709570 (4626), & below)
Index
No.
Skyjack
Part No.
DescriptionQty.
