SECTION 3, Page 3SJIII Series - The Conventionals 129919
Figure 3.1-2. Tilt Switch Usage Chart
10196AA
NOTE: Ensure the platform
is parked on a flat level sur-
face before performing any
adjustments or repairs to the
tilt switch assembly.
ANSI Models CE Models AS Models
Tilt switch
(X Axis° x Y Axis°)
Tilt switch
(X Axis° x Y Axis°)
Tilt switch
(X Axis° x Y Axis°)
Model
Serial
Numbers
124138
(1.5° x 3.5°)
117880
(2.5° x 4.5°)
Serial
Numbers
124138
(1.5° x 3.5°)
117880
(2.5° x 4.5°)
Serial
Numbers
124138
(1.5° x 3.5°)
118058
(1° x 2°)
3220
From
610500
to present
X
From
611631
to 615052
X
From
610500
to present
X
3226
From 27013
to present
X
From
27013
to 270981
X
From 27013
to present
X
4620
X
From
66703 to
66871
X X
4626
X
From
706569 to
709312
X X
4632
From
710000
present
X Not Applicable
From
710000
present
X
60041AD_1
