Skyjack 4632 - Page 37

SECTION 3, Page 4 SJIII Series - The Conventionals 129919
Figure 3.1-3. Electrical Symbol Chart
WIRE CROSSING HOURMETER
LEVEL SENSOR
KEY SWITCH
WIRES JOINED LIGHT
SINGLE POLE
SINGLE THROWN
RELAY
FOOT SWITCH
BATTERY
HYDRAULIC
VALVE COIL
SINGLE POLE
DOUBLE THROW
RELAY
TOGGLE SWITCH
GROUND
PROPORTIONAL
HYDRAULIC
VALVE COIL
DOUBLE POLE
SINGLE THROW
RELAY
PUSH BUTTON
FUSE
ELECTRIC
MOTOR
DOUBLE POLE
DOUBLE THROW
RELAY
ROTARY SWITCH
CIRCUIT
BREAKER
HORN
TRIPLE POLE
DOUBLE THROW
RELAY
LIMIT SWITCH
BATTERY
CHARGE
INDICATOR
EMERGENCY
STOP BUTTON
DIODE
CAM OPERATED
LIMIT SWITCH
CAPACITOR RESISTOR
TRANSISTOR
TILT SWITCH
POTENTIOMETER
ANGLE
TRANSDUCER
PRESSURE
TRANSDUCER
LIMIT SWITCH
N.O.
LIMIT SWITCH
N.O. HELD
CLOSED
LIMIT SWITCH
N.C.
LIMIT SWITCH
N.C. HELD
OPEN
SILICON
CONTROLLED
RECTIFIER
PROXIMITY
SWITCH
PNP
TRANSISTOR
NPN
TRANSISTOR
PRESSURE/
VACUUM
SWITCH
TEMPERATURE
SWITCH
