Skyjack 4632 - Page 44

SECTION 3, Page 13SJIII Series - The Conventionals 129919
R2
LIFT RELIEF
VALVE
2H-13
LOWERING
VALVE
4H-15
REVERSE
DRIVE
VALVE
R1
SYSTEM
RELIEF
VALVE
4H-23
RIGHT STEER
VALVE
CB1
COUNTER-
BALANCE
VALVE
3H-14
LIFT
VALVE
3H-17A
BRAKE
VALVE
02
LOWERING
ORIFICE
R5
RELIEF
VALVE
FD1
FLOW
DIVIDER/COMBINER
VALVE
R4
RELIEF
VALVE
4H-16
FORWARD
VALVE
3H-18A-2
SPEED
VALVE B
2H-18A
DIFFERENTIAL
VALVE
3H-18A-1
SPEED
VALVE A
2H-59B
PROPORTIONAL
VALVE w/ BUILT-IN
COMPENSATOR
VALVE
MAIN MANIFOLD
PROPORTIONAL
MANIFOLD
REAR DRIVE MANIFOLD
10192AC
Figure 3.2-5. Hydraulic Manifold Component And Port Identification
V2
FREE-WHEELING
VALVE
(Model 4620/4632 only)
CMP1
COMPENSATOR
VALVE
2H-59B
PROPORTIONAL
VALVE
QUICK
DISCONNECT
(IF EQUIPPED)
QUICK
DISCONNECT
(IF EQUIPPED)
4H-24
LEFT STEER
VALVE
IF EQUIPPED
11542AA
AF
11554AA
AUTO RESET
VALVE
HAND PUMP
HYDRAULIC
FITTING
BRAKE RELEASE
MANIFOLD
