SECTION 3, Page 14 SJIII Series - The Conventionals 129919
129ACR 108589 1 RELAY, 24 Volt (Joystick enable switch) - CE & ANSI/CSA with All Option
17CR 108589 1 RELAY, 24 Volt (Transfer)
21ACR 108589 1 RELAY, 24 Volt (Proportional) - CE
21CCR 108589 1 RELAY, 24 Volt (Proportional) - ANSI/CSA
28CR 108589 1 RELAY, 24 Volt (Tilt switch) - ANSI/CSA
28CR1 108589 1 RELAY, 24 Volt (Tilt) - CE
28CR2 108589 1 RELAY, 24 Volt (Down) - CE
28ECR1 108589 1 RELAY, 24 Volt (Auxiliary Tilt) - CE
28ECR2 108589 1 RELAY, 24 Volt (Auxiliary Down) - CE
2H-13 103605 1 COIL, 24 Volt (Down valve) - ANSI/CSA
2H-13B 103605 1 COIL, 24 Volt (Down valve) - CE
2H-13-X 104493 AR COIL, 24 Volt (Holding valve) - ANSI/CSA
2H-13B-X 104493 AR COIL, 24 Volt (Holding valve) - CE
2H-18A 103605 1 COIL, 24 Volt (Differential valve)
2H-59B 115370 1 COIL, 24 Volt (Proportional valve)
3H-14A 105610 1 COIL, 24 Volt (Lift valve) - ANSI/CSA
3H-14 105610 1 COIL, 24 Volt (Lift valve) - CE
3H-17A 103605 1 COIL, 24 Volt (Brake valve)
3H-18A-1 103605 1 COIL, 24 Volt (Speed A)
3H-18A-2 103605 1 COIL, 24 Volt (Speed B)
4H-15 128320 1 COIL, 24 Volt (Reverse drive spool valve)
4H-16 128320 1 COIL, 24 Volt (Forward drive spool valve)
4H-23 128320 1 COIL, 24 Volt (Right steer spool valve)
4H-24 128320 1 COIL, 24 Volt (Left steer spool valve)
4H-26 103605 1 COIL, 24 Volt (Powered platform extend spool valve) (Option)
4H-27 103605 1 COIL, 24 Volt (Powered platform retract spool valve) (Option)
8BCR 108589 1 RELAY, 24 Volt (Joystick enable switch) - ANSI/CSA No Option
AT1 (Ref.) 1 TRANSDUCER, Angle - CE
(For components refer to the load sensing supplement manual)
B1-B4 106552 4 BATTERY, 6V (Interstate #U2500)
103480 4 BATTERY, 6V (Interstate #U2200)
BC 128537 1 CHARGER, Battery 24VDC (Superior Universal)
BCI 122093 1 BATTERY CHARGE INDICATOR
BP-29 103057 1 BEEPER, 24 VDC (ANSI/CSA)
117967 1 BEEPER, 9-28 VDC (CE)
C1 103101 1 CONTACTOR, 24 Volt motor
CAP1 110699 1 CAPACITOR .47UF 50 Volts
CB1-CB2 117325 2 CIRCUIT BREAKER, 15 Amp
CM1 (Ref.) 1 CONTROL MODULE, Integrated Sensor (CE)
(For components refer to the load sensing supplement manual)
Parts list continued on the following page.
Figure 3.3-1. Electrical Schematic And Diagram Parts List
Index
No.
Skyjack
Part No.
DescriptionQty.
AH
