SECTION 3, Page 15SJIII Series - The Conventionals 129919
Figure 3.3-1. Electrical Schematic And Diagram Parts List (Continued)
Index
No.
Skyjack
Part No.
DescriptionQty.
Parts list continued from the previous page.
DCM1 123477 1 MOTOR, 24 Volt
D02-X 129258 AR DIODE
DXX 102921 AR DIODE
DA1 119758 1 DIODE PACK
DA2 119520 1 DIODE ASSEMBLY
DA3 119624 1 DIODE ASSEMBLY
F1 117619 1 FUSE, 300 Amp
FL-22 121477 1 FLASHING LIGHT (option)
FL-22A 103743 1 FLASHER, Flashing Light
H1 121058 1 HORN, Operator
INV1 128769 1 INVERTER, 24VDC - 120 VAC @ 60 Hz (ANSI/CSA)
128770 1 INVERTER, 24VDC - 110/220 VAC @ 50 Hz (CE)
L1CR 115315 1 RELAY, Battery charger
LB1 102671 1 MOUNT, Load Sensing Light Assembly (CE)
LS1A 121975 1 LIMIT SWITCH, High speed - Model 32xx
121975 1 LIMIT SWITCH, High speed - Model 46xx (ANSI/CSA)
133599 1 LIMIT SWITCH, High speed - Model 46xx (CE)
LS1B 121975 1 LIMIT SWITCH, High speed - Model 32xx
121975 1 LIMIT SWITCH, High speed - Model 46xx (ANSI/CSA)
133599 1 LIMIT SWITCH, High speed - Model 46xx (CE)
LS3 122014 1 LIMIT SWITCH, End of stroke (Option)
LS4 125887 1 LIMIT SWITCH, Pothole protection - Battery tray - Model 32xx
125887 1 LIMIT SWITCH, Pothole protection - Battery tray - Model 46xx (ANSI/CSA)
133601 1 LIMIT SWITCH, Pothole protection - Battery tray -Model 46xx (CE)
126051 1 LIMIT SWITCH, Pothole protection - Battery tray (ANSI/CSA EE-Rated)
LS5 125885 1 LIMIT SWITCH, Pothole protection - Hydraulic tray - Model 32xx
125885 1 LIMIT SWITCH, Pothole protection - Hydraulic tray - Model 46x (ANSI/CSA)
133600 1 LIMIT SWITCH, Pothole protection - Hydraulic tray -Model 46xx (CE)
126060 1 LIMIT SWITCH, Pothole protection - Hydraulic Tray (ANSI/CSA EE-Rated)
LS6 121975 1 LIMIT SWITCH, Drive override - Model 32xx
121975 1 LIMIT SWITCH, Drive override - Model 46xx (ANSI/CSA)
133599 1 LIMIT SWITCH, Drive override - Model 46xx (CE)
PS1 102863 1 PRESSURE SWITCH
PT1 (Ref.) 1 TRANSDUCER, Pressure- CE
(For components refer to the load sensing supplement manual)
PWM 122868 1 CIRCUIT BOARD ASSEMBLY, Proportional Controller
Parts list continued on the following page.
