SECTION 3, Page 16 SJIII Series - The Conventionals 129919
Parts list continued from the previous page.
RST1 119629 1 RESISTOR, 2.7K
RST2 115313 1 RESISTOR, 25W-30 Ohm
RST3 116505 1 RESISTOR, Low voltage protection
S1 119725 1 SWITCH, Main power disconnect
S2 103141 1 N.O. CONTACT, Up/Down (Base Control Box )
S3 103141 2 N.O. CONTACT, On/Off Key switch (Main Control Box)
S4 103225 1 N.C. CONTACT, Emergency stop switch (Main Control Box)
S5 116382 1 SWITCH, Lift/Off/Drive toggle (Main Control Box)
S7 123994 1 CONTROLLER ASSEMBLY, Proportional (Main Control Box)
S8 103141 1 N.O. CONTACT, Operator horn (Main Control Box)
S10 (Ref) - ASSEMBLY, Base Control Box Enable Base Contact - Model 46XX
103141 1 • N.O. CONTACT, Base Control Box Enable
103225 1 • N.C. CONTACT, Base Control Box Enable (ANSI/CSA only)
S11 102853 1 SWITCH, Powered extension platform extend/retract toggle (Option)
S12 102853 1 SWITCH, Powered extension platform enable toggle (Option)
S27 115574 1 SWITCH, Torque toggle
S28 103225 1 N.C. CONTACT, Emergency stop switch (Base Control Box)
TMR-19A 137417 1 RELAY, Inverter Timer Cut-Out (ANSI/CSA)
(Order P/N 132494 for machines with Serial No. 618279 (3220),
275999 (3226), 715239 (4620), 714944 (4626), 714576 (4632), & below)
TMR-19B 137417 1 RELAY, Inverter Timer Cut-Out (CE)
(Order P/N 132494 for machines with Serial No. 618279 (3220),
275999 (3226), 715239 (4620), 714944 (4626), 714576 (4632), & below)
TS1 117880 1 TILT SWITCH (ANSI/CSA)
TT 103336 1 HOURMETER
Index
No.
Skyjack
Part No.
DescriptionQty.
Figure 3.3-1. Electrical Schematic And Diagram Parts List (Continued) AH
To Next Page
