Section 2 - Operation Start Operation
DANGER
The drive orientation can change when
the turret is swung 90 degrees off center
of the normal driving position (roughly
when boom is swung past the rear tire).
Drive re-orientation will not occur while
driving and rotating until the joystick
is released for 6 seconds or when the
footswitch is released.
WARNING
DRIVING ON A SLOPE
When driving on a slope •
greater than 30%, the platform
capacity is limited to 300 lb.
(136 kg).
The platform must be between •
the non-steer wheels and
must be on the downside of
the hill.
When slope increases to •
above 45%, the forward drive
is disabled but reverse drive
remains active.
2.10-12 To Steer
1. Depress and hold footswitch.
2. On platform control console, press rocker on top
of drive/steer controller in this direction “
” to
steer left or “
” to steer right.
NOTE
Driving and steering may be active at the
same time.
2.10-13 To Move Jib (If Equipped) Up and
Down Using Platform Control Console
1. Depress and hold footswitch.
2. On jib up/down switch, select “
” to move jib
up or “
” to move jib down. Release switch
to stop.
2.10-14 To Move Riser Up and Down Using
Platform Control Console
1. Depress and hold footswitch.
2. On riser up/down switch, select “
” to move
riser up or “
” to move riser down. Release
switch to stop.
2.10-15 To Extend or Retract Fly Boom Using
Platform Control Console
1. Depress and hold footswitch.
2. On fly boom extend/retract switch, select “
”
to extend fly boom or “
” to retract fly boom.
Release switch to stop.
2.10-16 To Rotate Platform Using Platform
Control Console
1. Depress and hold footswitch.
2. On platform rotation switch, select “
” to rotate
platform left or “
” to rotate platform right.
2.10-17 To Level Platform Manually Using
Platform Control Console
1. Depress and hold footswitch.
2. On platform leveling override switch, select
“
” up position to tilt platform up or
“
” down position to tilt platform down.
