Skyjack SJ6826 RT - Drive and Tie-Down the MEWP

65
SJ6826 RT, SJ6832 RT
221587ABA
Move the MEWP for transport Section 6 – Additional Procedures
ZZ
P
S
I
/
B
A
R
M
A
N
U
A
L
=
�������
=
M
A
N
U
A
L
B
A
R
124631AC
��������
������
�
3
3
Figure 08 MEWP Center of Gravity
2
2
Figure 07 Tie-downs/lift points
.
NOTE
For the weight of the MEWP, refer to
section 7.3. Horizontally, the center of gravity
3
is approximately in the middle of the MEWP,
front to back and side to side. Refer to Figure 08.
Vertically, the center of gravity is approximately a
small distance above the chassis.
6.4-3 Drive and tie-down the MEWP
Before you drive the MEWP:
▪
The ramp or dock capacity must be able to hold
the maximum MEWP weight.
▪
Use side guards (if available) to prevent a fall
from the ramp.
▪
The incline of the ramp must not exceed the
MEWP gradeability. Refer to section 7.3.
▪
Do a test of the MEWP brakes to make sure they
operate correctly.
▪
Move the inclined-drive/level-drive switch to the
inclined-drive (low speed/high torque) position.
WARNING
When you transport the MEWP, it must be attached
to a truck or trailer deck. Use the available
tie-down points
2
to attach the MEWP. Refer to
Figure 077. If you do not obey, there is a risk of
death or serious injury.
▪
Tie-down the MEWP to the transport vehicle
using the tie-down points
2
. Refer to
Figure 077.
