Page 52 December 2007
Rough Terrain Scissors
Start Operation Section 3 - Operation
3.8-11 Generator (If Equipped)
To start the hydraulic generator:
1. On platform control console, select off/lift/drive
key switch to “ ” lift position.
2. Depress and hold “ ” engine start pushbutton
to start the engine.
3. On auxiliary control console, select hydraulic
generator switch to “ ” energized position. Engine
will automatically switch to high throttle and
generator will start.
To stop the hydraulic generator:
1. Select hydraulic generator switch to “ ” off
position. The generator will turn off and throttle
will return to selected speed.
NOTE
Activating any lift or outrigger functions,
changing the key switch setting, activating
the emergency stop or an engine stall will
turn off the generator. The platform may be
lowered during generator operation.
3.8-12 Shutdown Procedure
1. Completely lower the platform.
2. On platform control console, push in “ ”
emergency stop button.
3. Select off/lift/drive key switch to “ ” off position
and remove key.
WARNING
Ensure that you maintain three points of
contact when using the ladder to mount/
dismount the platform.
4. Use the ladder to dismount from platform.
5. On base control console, push in “ ” emergency
stop button.
6. On off/platform/base key switch, select “ ” off
position and remove key.
7. On engine control console, select engine off/on/
start switch to “ ” off position.
8. Turn main power disconnect switch to “ ” off
position.
