Spacers
Preparation spacers AX
Fix a sealant C3 (8-11 and 16 mm) or CY10 (8 & 9 mm) on every spacer.
Installation spacers AX
A spacer AX is clipped between the rafter profiles at the gutter and walls side.
C3
AX
CY10
AX
CLICK
C3 (CY10)
C3 (CY10)
AX
CLICK
