Overview of Climalux profiles and parts
CLSB BASE SCREWABLE CLIP
CLST
TOP SCREWABLE CLIP
FOR 8 TO 16 MM
CLSL TOP SCREWABLE CLIP
PX POST 110/141 FOR GUTTER GX
PGDX POST 110/110 FOR CROSSBEAM GDX
PXLX
POST BASE 150 x 120
FOR GUTTER GX/GXLX
PCLXLX
POST CLIP 150 x 60
TO COMBINE WITH GUTTER GXLX
PCLX
POST CLIP 150 x 30
TO COMBINE WITH GUTTER GX
C1CX
COEX RUBBER WHITE/BLACK
COEX RUBBER GREY/BLACK FOR
WALL PROFILE MX
C3
GREY RUBBER FOR SPACER OR SIDE
RAFTER
CY10
GREY RUBBER FOR SPACER OR SIDE
RAFTER
C8 GREY RUBBER FOR CL16 AND CLSB
AX SPACER
U16P
REINFORCED PVC END PROFILE
16 MM WHITE
U16A ALU END PROFILE 16 MM
U16 PRE-DRILLED ALU END PROFILE 16 MM
U32
PRE-DRILLED ALU END PROFILE
32 MM
ACCESSORIES
RUBBERS
POSTS
