Overview of Climalux profiles and parts
PU U TOP-BOTTOM FOR POST PX
PUX U TOP-BOTTOM FOR POST PGDX
PT150 TOP PLATE FOR GXLX
LT150 L-BRACKET TOP FOR POST PXLX
LB150 L-BRACKET BOTTOM FOR POST PXLX
VGXLX CONNECTING PROFILE 2 GXLX
BMR
STAINLESS STEEL BOLT, NUT AND
WASHER M8
GC WATER OUTLET + SWIVEL Ø 80 mm
UGS
WUGS
UNIVERSAL OUTLET +
SWIVEL FOR OUTLET
ZSB
ZSG
ZSC
SELF-DRILLING SCREW SST
SELF-DRILLING SCREW PAINTED SST
SELF-DRILLING SCREW SST WITH SEAL
6,3 x 25
SELF-DRILLING SCREW 6.3 x 25 mm
ZSR PLUG HSA 8175
49691 M10 X 20
72911 M10 TOOTHED WASHER
72910 M8 X 16
72912 M8 TOOTHED WASHER
71906
SST STEEL SCREW 4.8 X 25 - TX25
FOR END PIECE GASXL
TX25
