HIGH BEAM INDICATOR LIGHT(4)
This indicator light comes on when the headlight
high beam is turned on.
LEFT/RIGHT TURNING SIGNAL INDICATOR
LIGHT(5)
This indicator light comes on when the direction
signal turns left or right.
LEFT HANDLEBAR
DIMMER SWITCH(1)
Turning the right handlebar in " " position, in
this time, the front and rear lightening lamps come
on to give the warning. Shifting the dimmer switch
into " " position, the headlamp high beam indicator
light comes on. Shifting the dimmer switch into " "
position, the front and rear position indicator lights
come on.
TURN SIGNAL SWITCH(2)
Turning the switch into " " position, the left turn
signal indicator will flash intermittently, shifting the
switch into " " position, the right turn signal indicator
will flash intermittently, while in central position, the
left and right turn signal indicator lamps do not work
altogether.
13
ST50-6, ST110-6 ST125-6
CONTROLS
KEY
This motorcycle comes equipped with a pair of
identical ignition keys. Keep the spare key in a safe
place.
IGNITION SWITCH
There are two positions for ignition switch:
"OFF" POSITION
All electrical circuit is disconnected.
"ON" POSITION
All electrical circuits are connected and the
engine can be started.
INSTRUMENT PANEL
SPEEDOMETER(1)
The speedometer indicates the road speed in
kilometers per hour.
ODOMETER(2)
The odometer registers the total distance that
motorcycle has been ridden.
NEUTRAL INDICATOR LIGHT(3)
The green neutral indicator light comes on when
the transmission is in neutral. When the
transmission if engaged in other gear, this light goes
out.
ST50-6 ST110-6, ST125-6
12
(1)ignition switch
