Skytec SPA800 User Manual

SPECIFICATION
Frequency Response: ...................................................... 40Hz-20kHz ± 3dB
Input Sound Source: ...................................................................... Line Input
Speaker: ...................................... 8 inch Woofer & Piezo Tweeter (170.143)
................................................... 10 inch Woofer & Piezo Tweeter (170.146)
................................................... 12 inch Woofer & Piezo Tweeter (170.149)
Car reader memory medium: ......................................... MMC Card, SD Card
Power supply: ..................................................................... 230VAC at 50Hz
FRONT PANEL:
1. 7-Bands master Equalizer Left
channel
2. LED VU-meter master signal
3. 7-Bands master Equalizer Right
channel
4. Microphone Input Socket
5. Microphone volume control
6. Echo control
7. Bass / Treble control
8. Master Volume control
9. Source selector
10. MP3 Play/Pause/Track buttons
11. SD/MMC Card Input
BACK PANEL:
21. Speaker output
22. Line input
23. Power switch
24. AC power cable

Skytec SPA800 Specifications

General

Impedance	8 Ω
Sensitivity	123 dB
Frequency range	50 - 20000 Hz
RMS rated power	300 W
Tweeter	Yes
Amplifier	Built-in
Speaker type	2-way
Number of speakers	2
Number of tweeter drivers	1
Woofer diameter (imperial)	8 \
Type	Freestanding Public Address (PA) system
Product color	Black
Volume control	Rotary
Equalizer bands quantity	5
Compatible memory cards	SD
Connectivity technology	Wired
AC input voltage	220-240 V
Power source type	AC
AC input frequency	50 Hz

Weight and Dimensions

Depth	245 mm
Width	310 mm
Height	510 mm
Weight	7500 g
