OPERATION:
Connect the passive speaker with a good quality speaker cable to the speaker output connector
(21). WARNING: only connected the original slave speaker on the speaker output terminal!
If required connect an external signal source like a CD-layer to LINE IN.
Connect the device with an electric outlet (230VAC / 50Hz)
It is possible to connect an external antenna to the antenna socket for optimum radio reception.
LINE INPUT (DVD, CD-player etc.):
1. Connect the source (DVD-player, CD-player etc.) to the line input on the rear panel
2. Slide the SOURCE select switch to DVD position.
USB/SD:
1. Slide the SOURCE select switch to USB position.
2. Press PLAY button, MP3 begin to play.
MICROPHONE:
1. Inset the microphone to the MIC1 or MIC2 jack.
2. Adjust the MIC volume and tone control.
3. Adjust the echo control.
Adjust the master VOLUME (8)
Adjust the master Equalizer (1+3) to get the right sound
WARNING:
Do not turn the volume at max when use this product at public place just like school, office etc.
After long time using the back panel will be hot, do not touch it by hand.
TROUBLE SHOOTING:
NO POWER The power line is cut off or not connected
No power on the electric outlet
NO SOUND Wrong input, check input selector
The connect line was broken
The volume knob at lowest
ONE SPEAKER WITHOUT SOUND
Connection between master & slave unit wrong
Signal line was broke
MICROPHONE NO SOUND The microphone not complete connected
Adjust the microphone volume
Change microphone
MICROPHONE HOWL The microphone is too close to the speaker
Master volume adjust too big
This appliance should not be put into the domestic garbage at the end of its useful life, but must be
disposed of at a central point for recycling of electric and electronic domestic appliances. This symbol on
appliance, instruction manual and packaging puts your attention to this important issue. The materials
used in this appliance can be recycled. By recycling used domestic appliances you contribute an
important push to the protection of our environment. Ask your local authorities for information regarding the
point of recollection.
Do not attempt to make any repairs yourself. This would invalid your warranty. Do not make any changes to the unit. This would also invalid
your warranty. The warranty is not applicable in case of accidents or damages caused by inappropriate use or disrespect of the warnings
contained in this manual. Tronios cannot be held responsible for personal injuries caused by a disrespect of the safety recommendations and
warnings. This is also applicable to all damages in whatever form.
