Skytec TEC6200 User Manual

OPERATION
1. Connect loudspeaker system (MINIMUM load 4 ohms) with sufficient handling capacity to the output terminals of the amplifier.
2. Connect output from mixer ( or any other suitable signal source) to the appropriate input sockets of the power amplifier.
NOTE. All inputs are UNBALANCED and connections for the XLR input are Pin 1 = Gnd, 2=+IN, 3= Gnd.
3. Connect the power cord to the mains.
4. Turn gain controls to minimum , switch on the amplifier and the red power LED will illuminate.
5. Adjust gain controls to required level. NOTE. If the audio input signal is too high, distortion will result and the CLIP indicator will light.
If the clip LED is lit permanently or flashes, the gain level should be reduced.
6. Protect LED. These power amplifiers feature a unique short circuit relay protection system. When the output is shorted the amplifier
will go into protect mode with the yellow LED illuminating. Switch OFF the unit and remove the short circuit. Switch ON the amplifier
and the output will be returned immediately.
For reliable and trouble free operation, please observe the following points:
• Ensure all input / output connections are correct and secure.
• The handling capacity of the loudspeakers is adequate for the output of the amplifier.
• Always site the amplifier in a well ventilated location
• Protect unit from severe shocks
3
TEC6200 TEC6300 TEC6500 TEC6950
Stereo output power RMS @ 0.1% THD 2 x 100W 2 x 150W 2 x 250W 2 x 500W
Maximum output power 2 x 200W 2 x 300W 2 x 500W 2 x 950W
Single channel driven 4Ω load 110W 165W 270W 540W
Load impedance minimum 4Ω 4Ω 4Ω 4Ω
Input connectors RCA phono socket RCA phono socket
1/4” (6.3mm) jack socket Combination XLR/jack
(mono) (1=Gnd, 2=+IN, 3=Gnd)
(mono)
Output connectors 1/4” (6.3mm) jack socket (mono) Speakon (+1 /-1)
Input sensitivity 775mV 4dBBu (1.2V)
Input impedance 10K 10k
Frequency response 20Hz-20kHz ±3dB
THD +N <0.05% @ 1kHz and rated power single channel
Signal to noise ratio > 90dB
Cross-talk > 50dB @ 1kHz
Protection Protection against short circuit and DC on output
Indicators Power on, CLIP-L, CLIP-R, PROTECT
Cooling 80mm fan 80mm fan 80mm fan 80mm fan
Mains power 230V, 50Hz
Power consumption 550VA 750VA 1100VA 2100VA
Fuses AC mains T3.15A T3.15A T5A T10A
DC T3.15A T3.15A T5A T12.5A
Dimensions (WxDxH) 482 x 88 x 330mm (2U) 482 x 88 x 335mm
Weight 10kg 10.3kg 10.5kg 14kg
