SkyTrac Systems Ltd.
Document Rev. 02.010 ISAT-100-OPD-SOI Page 8 of 26
Restricted Proprietary and Confidential Information
6. Create the wire harness for the ISAT-100. Refer to ISAT-100 Optional Equipment
Wiring Diagram (DOC0029) if the applicable STC drawings are not available.
7. If a PDA is going to be connected to the ISAT-100, check the data port using a
PDA loaded with ITrax software. Refer to the ITRAX manual for more information.
8. If a PDA is used:
• Make sure it has a serial connector
• RS 232 cable should not exceed 40 ft.
1. Must use shielded RS 232 cable
4.4 ISAT-100 Installation
The ISAT-100 is designed to be secured by its mounting rails to the airframe using six
(6) AN-3 bolts and should be installed using the ISAT installation kit (P/N KIT-ISAT-
100). Figure 4-1: ISAT-100 Mounting Rails illustrates the locations for mounting
screws in the mounting rails on the sides of the ISAT-100.
It is important to achieve a good electrical bond between the ISAT-100 enclosure
and the airframe. Remove paint if necessary and prepare the mounting holes.
