Table 4-1 System Connector - Pin Description
19 Pin System Connector
Pin # Description
A +28 VDC Main Power In
B Ground (Power)
C Battery Disconnect
D Analog Input #1 0-30VDC
E Analog Input #2 0-30VDC
F Analog Input #3 0-30VDC
G Analog Input #4 0-30VDC
H Analog Input #5 0-30VDC
J Voltage Seeking - Digital Input #1 (Mission Switch)
K Voltage Seeking - Digital Input #2
L Ground Seeking - Digital Input #3
M Voltage Seeking - Digital Input #4
N Ground Seeking - Digital Input #5 (Squat/Collective)
P Voltage Seeking - Digital Input #6 (Engine On/Off)
R Ground Seeking - Digital Input #7 (Emergency)
S Current Sinking Digital Output #1
T Current Sinking Digital Output #2
U Current Sinking Digital Output #3
V Differential GPS Input
The above digital inputs on Pin N, P & R are set as factory default. Contact your
SkyWeb Hardware Manager if different configuration is required.
