Skytrac ISAT-200R User Manual

SkyTrac Systems Ltd.
Document Rev. 01.020 DOC0334 Page 31 of 49
Restricted Proprietary and Confidential Information
4.2.8 Analogue Inputs
Table 25—Analogue Input Descriptions
ISAT-200R
Description and recommended usage
Pin #
Bay A
Bay B
30
Analogue Input Channel 1*
67
Analogue Input Channel 2 (Reserved. Do not use)
68
Analogue Input Channel 3 (Reserved. Do not use)
69
Analogue Input Channel 4*
80
Analogue Input Channel 5*
* Analogue inputs 1, 4 and 5 can be configured as voltage seeking digital inputs. Analogue input
1 is the recommended alternate input for Engines On/Off toggle switch if a voltage seeking
input is required.
4.2.9 Auxiliary Power Output
Table 26—Auxiliary Power Description
ISAT-200R
Description and recommended usage
Bay A Pin #
13
6 VDC, 0.8 A short circuit protected, thermal shutdown protected.
14
Auxiliary Output Ground
4.2.10 External Power Input (28V)
Table 27—External Power Input Description
ISAT-200R
Description and recommended usage
Bay A Pin #
15
This pin connects to the aircraft power systems and supply power to the
ISAT-200
16
Power Ground (28VDC Return)
IMPORTANT NOTICE:
The auxiliary power output does not operate when the ISAT is operating under internal battery power.
