33
TECHNICAL DATA
Tonic EN/LTF : B 56-80kg B 65-100kg
C C 81-105kg C 105-114kg
Size 14 16 18
Cells 26 26 26
Surface Area (flat) 16,79 19,00 21,35
Flat Span: 8,37 8,91 9,44
Flat Aspect Ratio 4,18 4,18 4,18
Projected Area 14,24 16,12 18,11
Projected Span 6,64 7,07 7,49
Projected Aspect Ratio 3,10 3,10 3,10
max. profil depth in cm 2,36 2,51 2,66
min. profil depth in cm 0,84 0,90 0,95
Average line length without risers in cm 4,80 5,10 5,41
Leinenverbrauch in m 190 202 214
Canopy weight kg 2,8 3,1 3,4
Launch weight from – to in kg. 56-91 56-105 65-114
Trimmer yes yes yes
Towing yes yes yes
Jet Flap Technologie yes yes yes
Motor certification with special risers no no no
CAUTION:
THE IDENTIFICATION PLATE IS PRINTED ON THE INSIDE OF THE STABILO. THE
NAME OF THE PILOT AND THE DATE OF FIRST FLIGHT MUST BE ENTERED
HERE. THE TYPE INSPECTION TAG IS PRESSED INTO THE MIDDLE CELL ABOVE
THE CHECKAIR STAMP. THE DATE OF THE INSPECTION MUST ALSO BE EN-
TERED.IF THIS LABEL IS MISSING, IT SHOULD BE ASSUMED THAT THE GLID-
ER IS AN UNINSPECTED PROTOTYPE.
