LINE SYSTEM
Thanks to extensive testing, the lines of the TONIC have a very high level of strength
with a very small diameter. Safety always remains a priority throughout our design and
construction process. For this reason, we have implemented an elaborate combination of
different Liros lines in the TONIC.
The skywalk TONIC is equipped with 3 A-, 3 B- as well as 3 C and 1 stabilo line.
The top lines of the last cell together with the stabilo top lines attach to the main stabilo
line, which lead directly to the B-riser.
The brake lines are not load bearing and lead from the trailing edge of the wing over
the main brake line throught the brake pulley on the C-riser to the brake handle. There
is a mark on the main brake line where the brake handle is knotted. The brake line set-
tings should not be changed, on the one hand to assure adequate brake travel in extreme
flight situations and while landing and on the other hand to avoid constant braking. For
better recognition, the A-lines and the A-riser are red and the stabilo line is red/yellow.
The B-lines are yellow, the main brake line and the brake spider are orange and all oth-
er lines are blue. The line locks are triangular, a plastic insert prevents the looped-in lines
from slipping as well as preventing accidental opening of the line locks.
The skywalk TONIC has 3 risers on each side.
>The A-lines lead directly to the A-riser.
> The B-lines and the Stabilo-Line lead to the B-riser.
> The C-lines lead to the C-riser.
