Skywalker ActivPlay APGD9B - Component Visuals

4
Before you begin, take a look at the drawings below to make sure you have all the parts. The numbers in the squares
to the left (key numbers) will help you identify the parts during assembly.
PART IDENTIFICATION
1
Tube 1 (x10)
Size:895mm
2
Tube 2 (x40)
Size:671mm
3
Tube 3 (x10)
Size:818mm
4
Tube 4 (x25)
Size:638mm
5
Tube 5 (x5)
Size:511mm
6
Tube 6 (x5)
Size:732mm
