Skywalker APB60SF09 - Page 10

10
STEP 7
11
ASSEMBLY
STEP 8
5
Lower Foam 8” (205
mm) (x6)
Joint (x6)
Put the lower foam (11) onto the tube as shown.
Unfold the enclosure net attached to the mat. Find the premade holes near
the middle of the net. Place a joint (5) into the hole from the inside of net.
Repeat this step until all joints have been placed inside the net.
Make sure
the joint
holes are
facing up
