11
STEP 9
3
Enclosure tube
(x1)
Insert an enclosure tube (3) into a joint (5) as shown.
Make sure the middle hole in the enclosure tube aligns with the hole in the
joint.
STEP 10
Secure the joint and enclosure tube with the screws (16) as shown.
Note: The self tapping screws can be difficult to screw in as the holes are not
prethreaded. Your included tool or a screwdriver will work, but a power drill
can makes things a little easier.
Self-tapping Screw (x1)
16
To Next Page
