Skywalker APB60SF09 - Page 12

12
ASSEMBLY
Then place the assembled enclosure tube (3) onto the leg tube and
secure together with a screw (16) as shown.
10
Middle Foam 11” (302
mm) (x1)
Slide the middle foam (10) onto the assembled enclosure tube (3) as shown.
STEP 11
STEP 12
16
Self-tapping Screw (x1)
