13
STEP 13
Repeat steps 9-12 to assemble the remaining five enclosure tubes (3).
STEP 14
9
Upper Foam 21” (545
mm) (x6)
Now place the upper foam (9) pieces onto the top of the enclosure tubes as
shown.
