Skywalker JTEC8B - Page 16

16
STEP 19
Starting from the enclosure door, lift one of the assembled poles and insert the straight tube (9) into the
socket. Repeat this process to assemble the 3 remaining poles.
Helpful tip: When inserting the enclosure poles, pull back on the middle of the poles!
ASSEMBLY
STEP 20
Insert the end caps (11) into the bottom of the sockets.
End Cap (x4)
11
Socket
Socket
Pull back
(11)
Socket
