Skywalker JTEC8B - Part Identification

4
Before you begin, take a look at the drawings below to make sure you have all the parts! The numbers in the squares
to the left (key numbers) will help you identify the parts during assembly.
PART IDENTIFICATION
1 2
3
4
5
6
7
8
Leg Brace (x4)
Enclosure Net (x1)
Jump Mat (x1) Frame Pad (x1)
Springs (x56)
Foam (x8)
9
Straight Tube (x4)
10
Curved Tube (x4)
11
End Cap (x4)
12
Pole Cap (x4)
T-joint (may be pre-
installed) (x4)
Socket (may be
pre-installed) (x4)
