Skywalker SMB036 - Page 10

10
ASSEMBLY
This step is a breeze. Insert the left handlebar with
foam (6) into the right handlebar with foam (7),
and secure with one self-tapping screw (9).
Insert one upright tube (8) into one side of the handle bar, and
secure using one self-tapping screw (9). Don’t tighten the screw
yet.
Repeat this step on the other side of the handle bar.
STEP 9
STEP 10
Left Handlebar
with Foam (x1)
Upright Tube (x2)
Right Handlebar
with Foam (x1)
Self-tapping
Screw (x1)
Self-tapping
Screw (x1)
6
8
7
9
9
(7)
(6)
(9)
(8)
(8)
(9)
(9)
